ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — MA 320, In=320 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT5S 400 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 320 A, 3-pole, F/F (front, fixed) terminals. Magnetic-only trip unit MA 320 (magnetic instantaneous short-circuit release, for motor protection). Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100434R1, EAN 8056221005111, ABB/SAP material 1200638187, catalogue code 83055697.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5S 400 MA 320-3200 3p FF
- ABB order code (MPN)
- 1SDA100434R1
- EAN / GTIN
- 8056221005111
- ABB / SAP material no.
- 1200638187
- Frame
- XT5 (400 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- MA 320
- Rated uninterrupted current In
- 320 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221005111
- SAP 1200638187
- Code 83055697
Product Documentation
More from ABB
ABB
ABB 2CCS800900R0241 S800-UVR36 Under voltage release 24 … 36 V AC / DC
ABB
Ekip LSI In=25A XT2 3P
1SDA067306R1
ABB
CMS-202CA SENSOR 25mm 40A Cable
2CCA880119R0001
ABB
ABB SACE Tmax XT4N 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=160 A, 4-Pole
1SDA068146R1
ABB
ABB S401-D25 Miniature Circuit Breaker — 1P, Type D, 25 A, 10 kA
2CCS571001R0251
ABB
ABB 1SDA050543R1 Toroidal CT ON D.185MM RCQ
ABB
ABB S202M-K15 Miniature Circuit Breaker — 2P, Type K, 15 A, 10 kA
2CDS272061R0457
ABB
KIT EF XT5 4 Pcs (KIT EF XT5 4PCS)
KIT EF XT5 4pcs
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA100434R1?
- 1SDA100434R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA100434R1.
- What is the HS code for 1SDA100434R1?
- The customs tariff (HS) code for 1SDA100434R1 is 8536.20.
- Who manufactures 1SDA100434R1?
- 1SDA100434R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA100434R1?
- Yes — the 1SDA100434R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA100434R1?
- The minimum order quantity is 1.
- Is 1SDA100434R1 available?
- Yes — 1SDA100434R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
