ABB SACE Tmax XT4H 160 Moulded-Case Circuit Breaker — Ekip In, In=40 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT4H 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 40 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip In. Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA068516R1, EAN 8015644024222, ABB/SAP material 1200638031, catalogue code 83053856.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT4 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT4H 160 Ekip In In=40A 3p FF
- ABB order code (MPN)
- 1SDA068516R1
- EAN / GTIN
- 8015644024222
- ABB / SAP material no.
- 1200638031
- Frame
- XT4 (160 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip In
- Rated uninterrupted current In
- 40 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644024222
- SAP 1200638031
- Code 83053856
Product Documentation
More from ABB
ABB
Ekip LS/In In=160A XT2 4P
1SDA067333R1
ABB
ABB SACE Tmax XT3S 250 Moulded-Case Circuit Breaker — TMD 80-800, In=80 A, 3-Pole
1SDA068216R1
ABB
ABB 1SDA066632R1 KEY LOCK Ronis Equal Fellow C FOR Motor Operator Between MORE C.BREAKERS XT2-XT4
ABB
ABB SN201-C40 Miniature Circuit Breaker — 1P+N, Type C, 40 A, 6 kA
2CSS255101R0404
ABB
ABB S803S-K8 Miniature Circuit Breaker — 3P, Type K, 8 A, 50 kA
2CCS863001R0407
ABB
ABB S204M-B6 Miniature Circuit Breaker — 4P, Type B, 6 A, 10 kA
2CDS274061R0065
ABB
ABB SACE Tmax XT2L 160 Moulded-Case Circuit Breaker — TMA 50-500, In=50 A, 4-Pole
1SDA067664R1
ABB
ABB SACE Tmax XT2H 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=10 A, 3-Pole
1SDA067857R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA068516R1?
- 1SDA068516R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA068516R1.
- What is the HS code for 1SDA068516R1?
- The customs tariff (HS) code for 1SDA068516R1 is 8536.20.
- Who manufactures 1SDA068516R1?
- 1SDA068516R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA068516R1?
- Yes — the 1SDA068516R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA068516R1?
- The minimum order quantity is 1.
- Is 1SDA068516R1 available?
- Yes — 1SDA068516R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
