ABB SACE Tmax XT2H 160 Moulded-Case Circuit Breaker — Ekip In, In=25 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2H 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 25 A, 4-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip In. Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA067897R1, EAN 8015644017934, ABB/SAP material 1200637773, catalogue code 83052096.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT2H 160 Ekip In In=25A 4p FF
- ABB order code (MPN)
- 1SDA067897R1
- EAN / GTIN
- 8015644017934
- ABB / SAP material no.
- 1200637773
- Frame
- XT2 (160 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip In
- Rated uninterrupted current In
- 25 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644017934
- SAP 1200637773
- Code 83052096
Product Documentation
More from ABB
ABB
Soft starter PSTX72-690-70 72A
ABB
ABB SACE Tmax XT3S 250 Moulded-Case Circuit Breaker — TMD 80-800, In=80 A, 4-Pole
1SDA068223R1
ABB
ABB S204M-K50 Miniature Circuit Breaker — 4P, Type K, 50 A, 10 kA
2CDS274061R0577
ABB
ABB SACE Tmax XT7L 800 Moulded-Case Circuit Breaker — Ekip M Dip In, In=800 A, 3-Pole
1SDA100990R1
ABB
ABB SACE Tmax XT4N 160 Moulded-Case Circuit Breaker — TMA 125-1250, In=125 A, 4-Pole
1SDA068107R1
ABB
ABB S401M-C1 Miniature Circuit Breaker — 1P, Type C, 1 A, 10 kA 2CCS571001R0014
ABB
XT5 W FP 400A 4P EF EF IEC
1SDA104686R1
ABB
ABB S402-D20 Miniature Circuit Breaker — 2P, Type D, 20 A, 10 kA
2CCS572001R0201
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA067897R1?
- 1SDA067897R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA067897R1.
- What is the HS code for 1SDA067897R1?
- The customs tariff (HS) code for 1SDA067897R1 is 8536.20.
- Who manufactures 1SDA067897R1?
- 1SDA067897R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA067897R1?
- Yes — the 1SDA067897R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA067897R1?
- The minimum order quantity is 1.
- Is 1SDA067897R1 available?
- Yes — 1SDA067897R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
