ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — Ekip M-In, In=100 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2S 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 100 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip M-In. Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA067832R1, EAN 8015644017286, ABB/SAP material 1200637525, catalogue code 83051680.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT2S 160 Ekip M-In In=100A 3p FF
- ABB order code (MPN)
- 1SDA067832R1
- EAN / GTIN
- 8015644017286
- ABB / SAP material no.
- 1200637525
- Frame
- XT2 (160 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip M-In
- Rated uninterrupted current In
- 100 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644017286
- SAP 1200637525
- Code 83051680
Product Documentation
More from ABB
ABB
Auxiliary Contact T7M 2Q 400V AC
AUX T7-T7M-X1 2Q 400Va.c.
ABB
Cable Clamp OZXE56 (1SCA022811R5920)
ABB
ABB SACE Tmax XT4H 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=100 A, 3-Pole
1SDA068513R1
ABB
ABB S403-K3 Miniature Circuit Breaker — 3P, Type K, 3 A, 10 kA 2CCS573001R0317
ABB
Ekip Touch Measuring LSI In=100A XT4 3P
1SDA100285R1
ABB
ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip Dip LSI, In=1000 A, 3-Pole
1SDA101435R1
ABB
ABB 2CCA880241R0001 CMS-121DR 18mm Open-Core Sensor up to 40A
ABB
ABB S801S-K63 Miniature Circuit Breaker — 1P, Type K, 63 A, 50 kA
