ABB SACE Tmax XT1C 160 Moulded-Case Circuit Breaker — TMD 20-450, In=20 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT1C 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 20 A, 3-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMD 20-450 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class C; rated ultimate short-circuit breaking capacity Icu = 25 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA080826R1, EAN 8015644873448, ABB/SAP material 1200446938, catalogue code 82501621.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT1 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT1C 160 TMD 20-450 3p FF
- ABB order code (MPN)
- 1SDA080826R1
- EAN / GTIN
- 8015644873448
- ABB / SAP material no.
- 1200446938
- Frame
- XT1 (160 A frame)
- Breaking-capacity class
- C
- Rated ultimate breaking capacity Icu (415 V AC)
- 25 kA
- Trip unit
- TMD 20-450
- Rated uninterrupted current In
- 20 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644873448
- SAP 1200446938
- Code 82501621
