ABB SACE Tmax XT2N 160 Moulded-Case Circuit Breaker — TMA 100-1000, In=100 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2N 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 100 A, 4-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMA 100-1000 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class N; rated ultimate short-circuit breaking capacity Icu = 36 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. EAN 8015644009458, ABB/SAP material 1000669186, catalogue code 8683786.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT2N 160 TMA 100-1000 4p FF
- EAN / GTIN
- 8015644009458
- ABB / SAP material no.
- 1000669186
- Frame
- XT2 (160 A frame)
- Breaking-capacity class
- N
- Rated ultimate breaking capacity Icu (415 V AC)
- 36 kA
- Trip unit
- TMA 100-1000
- Rated uninterrupted current In
- 100 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644009458
- SAP 1000669186
- Code 8683786
Product Documentation
More from ABB
ABB
Contactor AF205-30-11-13 (AF205-30-11-13 100-250V 50/60Hz / Dc)
AF205-30-11-13 100-250V 50/60Hz / DC
ABB
Light-/TEMP.Sensor (6146/10)
ABB
ABB 2TKA00000451 Impressivo Recessed Euro Socket Outlet 3-Way Aluminium
ABB
SAGA WALL-Mounted 5 Switch Series IP44
1065SW-916
ABB
ABB Impressivo Rocker Switch, 1-Pole, with Window, White
2CKA001751A3091
ABB
ABB 1SL0255A00 INNER DOOR-SIZE 5 Gemini IP66 Insulating switchboards accessories
ABB
Jussi Recessed RCD (2CCF019494R0001)
ABB
Frame 3-Hole, 80mm, black matt
1723-885K
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XT2N 160 TMA 100-1000 4p F F?
- XT2N 160 TMA 100-1000 4p F F can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is XT2N 160 TMA 100-1000 4p F F.
- What is the HS code for XT2N 160 TMA 100-1000 4p F F?
- The customs tariff (HS) code for XT2N 160 TMA 100-1000 4p F F is 8536.20.
- Who manufactures XT2N 160 TMA 100-1000 4p F F?
- XT2N 160 TMA 100-1000 4p F F is a ABB product in the Electrical Components range.
- Is a datasheet available for XT2N 160 TMA 100-1000 4p F F?
- Yes — the XT2N 160 TMA 100-1000 4p F F datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XT2N 160 TMA 100-1000 4p F F?
- The minimum order quantity is 1.
- Is XT2N 160 TMA 100-1000 4p F F available?
- Yes — XT2N 160 TMA 100-1000 4p F F is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
