ABB SACE Tmax XT1C 160 Moulded-Case Circuit Breaker — TMD R63, In=63 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT1C 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 63 A, 4-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMD R63 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class C; rated ultimate short-circuit breaking capacity Icu = 25 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA067404R1, EAN 8015644012984, ABB/SAP material 1000669181, catalogue code 8366295.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT1 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT1C 160 TMD R63 4p FF
- ABB order code (MPN)
- 1SDA067404R1
- EAN / GTIN
- 8015644012984
- ABB / SAP material no.
- 1000669181
- Frame
- XT1 (160 A frame)
- Breaking-capacity class
- C
- Rated ultimate breaking capacity Icu (415 V AC)
- 25 kA
- Trip unit
- TMD R63
- Rated uninterrupted current In
- 63 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644012984
- SAP 1000669181
- Code 8366295
Product Documentation
More from ABB
ABB
Impressivo 2-H KAP without BOX 40/100 White
1722S100-84
ABB
ABB SACE Tmax XT3S 250 Moulded-Case Circuit Breaker — In=600 A, 4-Pole
1SDA068277R1
ABB
WALL-Mount Cabinet CA35V 800X800X160MM. IP44 (2CPX052216R9999)
ABB
WALL-Mount Cabinet TL507G 1100X1300X275MM IP55
2CPX010089R9999
ABB
ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — TMD 12,5-125, In=12.5 A, 4-Pole
1SDA067570R1
ABB
ABB 1SL0309A00 Panel WITH Holes H150 AND DIN-SIZE 4-5;PANEL WITH Holes H150 AND DIN-SIZE 4-5
ABB
FLA. x THE COMPART. DOOR x RC XT4 W 4P
1SDA066650R1
ABB
WALL-Mount Cabinet TW106G 950X300X350MM IP55
