MBG432 DIN-rail module
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CPX041658R9999 — Interior fitting module, CombiLine, Flatpack (unmounted), for DIN rail mounting devices, Grid unit 2 GU = 300 mm, panel width 3 = 750 mm, 72 Space units, Row distance in mm: 150, assembled with DIN rail 35 x 15 mm with perforation for wire holders, DIN rail 3 panel wide and more are with additional stabilization profile, covers out of Plastic, 90 degree press and turn closure, RAL 7035, Design of the cover: with cut-out, usable as of the cabinet depth of 120 mm.
Technical Specifications
- Manufacturer part number (MPN)
- 2CPX041658R9999
- EAN / GTIN
- 4011617416586
- Sales unit
- pcs
- Number of DIN Rails for Mounting
- 2
- Number of Modular Spacings per DIN Rail
- 36
- Number of Panel Heights
- 2
- Number of Rows
- 2
- Enclosure Mounting Frame
- WR or EDF
- Enclosure Type
- Interior fitting module
- Enclosure Type of Height
- 000
- DIN Place Units
- 72
- Meter Boards
- 0
- Module Function
- DIN rail mounting devices
- Rated Operational Voltage
- Maximum 400 V
- Operational Voltage
- 400 V
- Rated Insulation Voltage (U i )
- 690 V
- Rated Impulse Withstand Voltage (U imp )
- 6 kV
- Color
- Light grey
- Number of Modules
- 72
- Product Net Width
- 750 mm
- Product Net Height
- 300 mm
- Product Net Depth / Length
- 120 mm
- Section Width
- 3
- Built-In Depth ( t 2 )
- 120 mm
- EPLAN Data
- 9AAF623198_EPLAN
- Declaration of Conformity - CE
- 2CPC100019X0201
- Instructions and Manuals
- 2CPC112193M5601
- ETIM 9
- EC002575 - Distributor assembly for serial built-in device
- eClass
- V11.0 : 27400620
- Object Classification Code
- U
- Standards
- DIN EN 61439-3; DIN EN 61439-2; DIN 43880
- Width
- 750 mm
- Height
- 300 mm
- Depth
- 120 mm
- Number of DIN-rails
- 2
- Country of origin
- Slovenia
Standards & Compliance
- HS Code
- 8538.10
Cross References
- EAN 4011617416586
- SAP 1000120103
- Code 81106155
Product Documentation
More from ABB
ABB
Tenton 5/10V Aluminium SL SBS/U10.0.1-83
2CKA006330A0050
ABB
ABB SACE Tmax XT6H 800 Moulded-Case Circuit Breaker — Ekip Dip LSI, In=630 A, 4-Pole
1SDA107597R1
ABB
PB 200mm 6 pcs, XT2-XT4 4P
1SDA066682R1
ABB
ABB SACE Tmax XT4L 160 Moulded-Case Circuit Breaker — Ekip In, In=100 A, 4-Pole
1SDA068578R1
ABB
ABB 1SDA105079R1 Rotary Handle Lock on the panel door type Ronis key lock open/closed, different keys for XT5..XT7
ABB
ABB VFI online double conversion,400V,27000W,RS232,USB,COM slot,includes 3X28X8AH batteries mounted linked and tested 4NWP103584C3010
ABB
ABB 1SDA066640R1 Plate FOR Mechanical Interlock FOR PLUG-IN Circuit-Breaker XT1
ABB
ABB S401-B6 Miniature Circuit Breaker — 1P+N, Type B, 6 A, 10 kA
