Residual Current Circuit Breaker WITH Overcurrent DS201 M C16 A10MA
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CSR275180R0164 DS201 M C16 A10, 10kA, 2mod, C kar, 16A, 1 pole+N, 10mA.
Technical Specifications
- Manufacturer part number (MPN)
- 2CSR275180R0164
- EAN / GTIN
- 8012542582311
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Power loss
- 4.5 W
- Number of poles (total)
- 2
- Number of protected poles
- 1
- Rated voltage
- 240 V
- Rated insulation voltage Ui
- 500 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Rated current
- 16 A
- Rated fault current
- 0.01 A
- Leakage current type
- A
- Current limiting class
- 3
- Rated short-circuit breaking capacity according to EN 61009
- 10 kA
- Disconnection characteristic
- Undelayed
- Voltage type
- AC
- Release characteristic
- C
- Concurrently switching neutral conductor
- Yes
- With interlocking device
- No
- Overvoltage category
- 3
- Pollution degree
- 2
- Ambient temperature during operating
- -25–55 °C
- Width in number of modular spacings
- 2
- Built-in depth
- 69 mm
- Anti-nuisance tripping version
- No
- Degree of protection (IP)
- IP20
- Connectable conductor cross section solid-core
- 1–25 mm²
- Connectable conductor cross section multi-wired
- 0.75–16 mm²
- Flush-mounted installation
- No
- Mounting method
- DIN rail
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 8012542582311
- SAP 1200456051
- Code 82516311
Product Documentation
More from ABB
ABB
WALL-Mount Cabinet CA25K 550X800X160MM. IP44
2CPX052290R9999
ABB
ADP MOUNTING Fixed TERM. x FP XT5 400A 4P 1
1SDA116190R1
ABB
KLC-S Key lock open N.20005 XT7M
1SDA107495R1
ABB
ABB SACE Tmax XT1B 160 Moulded-Case Circuit Breaker — TMD R125, In=125 A, 3-Pole
1SDA066808R1
ABB
Impressivo SENT.PL Signal Light Black Matte
2TKA00004112
ABB
Residual Current Circuit Breaker F202 A S-100A/100MA
2CSF202201R2900
ABB
Cover frame TZP505 750X1250X30MM
2CPX010654R9999
ABB
ABB SACE Tmax XT1N 160 Moulded-Case Circuit Breaker — TMD 40-450, In=40 A, 4-Pole
