Residual Current Circuit Breaker F202 A S-100A/300MA
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CSF202201R3900 — The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Technical Specifications
- Manufacturer part number (MPN)
- 2CSF202201R3900
- EAN / GTIN
- 8012542916109
- HS code
- 8536.90
- Sales unit
- pcs
- Carbon Footprint (Full Lifecycle)
- 8.966856 kg CO₂ eq
- EcoSolutions Profile
- 9AKK108469A3794
- Recyclability Rate of the Product acc. to EN45555
- Design for Closing Resource Loops - Standard EN45555 - 82.05 %
- ABB Site Meeting Group Waste To Landfill Target
- No non-hazardous waste is sent to a landfill; UL 2799 Zero Waste To Landfill Validation available
- Sustainable Material Content in Packaging (wt. %)
- Recycled Paper - 0 %; Recycled Paper - 3.91 %; Recycled Cardboard - 29.08 %; Recycled Cardboard - 61.23 %; Recycled Cardboard - 2.66 %
- Extended Product Lifetime
- Product Durability
- Offered with Takeback Services
- Take Back for Recycling
- End Of Life Disassembling Instructions
- 9AKK108470A1748
- Environmental Product Declaration - EPD
- 9AKK108469A9642
- Type of Residual Current
- Type A
- Test Voltage (Out)
- 110-254 V
- Maximum Surge Current
- 5 kA
- Leakage Current Type
- A
- Power Supply Connection
- Arbitrary
- Electrical Endurance
- 10000 cycle
- Mechanical Endurance
- 20000 cycle
- Number of Poles
- 2P
- Number of Modular Spacings per DIN Rail
- 2
- Operating Characteristic
- Selective
- Tightening Torque
- 2.8 N·m
- Accessory Type
- Auxiliary contact; Auxiliary/Signal contact; Shunt trip; Undervoltage release; Overvoltage release; Motor Operating Device; Autoreclosing Unit
- Screw Terminal Type
- Cage Terminal
- Options Provided
- None
- Accessories Available
- Yes
- Connecting Capacity
- Busbar 10 mm²; Rigid 35 ... 35 mm²; Flexible 35 ... 35 mm²
- Rated Cross-Section
- 4 - Multi-Wired 0...35 mm²; 1 - Solid-Core 35...35 mm²
- Wire Stripping Length
- Top 12.7 mm; Bottom 14.9 mm
- Terminal Type
- Screw Terminals
- Rated Voltage (U r )
- 230 V
- Rated Operational Voltage
- 230 V
- Rated Insulation Voltage (U i )
- 500 V
- Rated Impulse Withstand Voltage (U imp )
- 4 kV
- Input Voltage Type
- AC
- Rated Current (I n )
- 100 A
- Rated Residual Current
- 300 mA
- Rated Conditional Short-Circuit Current (I nc )
- 10 kA
- Frequency ( f )
- 50/60 Hz
- Rated Frequency (f)
- 50/60 Hz
- Power Loss
- at Rated Operating Conditions per Pole 6.5 W; Total 13 W
- RAL Number
- RAL 7035 - Light Grey
- Number of Modules
- 2
- Maximum Operating Voltage UL/CSA
- 277 V AC
- Ambient Air Temperature
- Operation -25 ... 55 °C; Storage -40 ... 70 °C
- Degree of Protection
- Terminals IP20; Housing IP40
- Pollution Degree
- 2
- Resistance to Vibrations
- 20 Cycles with Load 0.8 In: 1g or 0.1mm 5...150...5 Hz
- Resistance to Shock acc. to IEC 60068-2-27
- 25g 2 shocks 13 ms
- Environmental Information
- Refer to RoHS
- Width in Number of Modular Spacings
- 2
- Product Net Width
- 35 mm
- Product Net Height
- 85 mm
- Product Net Depth / Length
- 69 mm
- Built-In Depth ( t 2 )
- 69 mm
- EPLAN Data
- 9AAC202083_EPLAN
- Declaration of Conformity - CE
- 9AKK106713A5602
- Instructions and Manuals
- 9AKK107991A6127
- Mounting Type
- DIN-Rail
- Mounting Position
- Any
- ETIM 9
- EC000003 - Residual current circuit breaker (RCCB)
- UNSPSC
- 39121601
- eClass
- V11.0 : 27142201
- IDEA Granular Category Code (IGCC)
- 4875 >> Residual current circuit breaker (RCCB)
- Object Classification Code
- F
- Standards
- IEC/EN 61008; UL 1053
