Undervoltagestrigger S2C-UA 12V DC
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CSS200911R0001 — The S2C-UA 12 DC undervoltage release has the function to protect the load in case of a voltage drop included between 70% and 35% of its rated value. Positive safety (device tripping when the voltage is disconnected) emergency stop by means of a button. Suitable for MCBs S200 series, RCCBs F200 series and RCBOs DS201, DS202C, DS200 series. It can be used with MCBs SN201 series by means of SN201-IH interface module. Rated voltage: 12V d.c.
Technical Specifications
- Manufacturer part number (MPN)
- 2CSS200911R0001
- EAN / GTIN
- 8012542839705
- Sales unit
- pcs
- Voltage
- 12 V
- Country of Origin
- India
- Product Sales Status
- Active
- Suitable For
- S200; S300P; SN201; F200; DS201; DS202C; DS200; DS203NC; DSE201 M; SD200; DS-ARC1; S-ARC1
- Suitable for Product Class
- Miniature Circuit Breakers MCBs; Residual Current Devices RCDs; Residual Current Breakers with Overload Protection RCBo
- Number of Switches
- 1
- Rated Voltage (U r )
- 12 V
- Power Loss
- Total 2.2 W
- Number of Contacts CO
- 0
- Number of Contacts NC
- 0
- Number of Contacts NO
- 0
- Environmental Information
- document not needed
- Product Net Width
- 18 mm
- Product Net Height
- 85 mm
- Product Net Depth / Length
- 74 mm
- Declaration of Conformity - CE
- 9AKK106713A5575
- Instructions and Manuals
- 2CSS490001D0010
- ETIM 9
- EC001286 - Auxiliary device for distribution board devices
- UNSPSC
- 39121010
- eClass
- V11.0 : 27143502
- IDEA Granular Category Code (IGCC)
- 4148 >> Under voltage coil
- Object Classification Code
- Q
- Voltage type for actuating
- DC
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 8012542839705
- SAP 1200640368
- Code 83057613
Product Documentation
More from ABB
ABB
CuAl kl 6X2.5-35MM2, XT4 3 pcs
1SDA066933R1
ABB
ABB S401-C40 Miniature Circuit Breaker — 1P, Type C, 40 A, 10 kA
2CCS571001R1404
ABB
ABB 1SCA022456R9620 OHG65J6T Pistol Handle
ABB
ABB S202M-Z15 Miniature Circuit Breaker — 2P, Type Z, 15 A, 10 kA
2CDS272061R0458
ABB
Ekip Touch LSI XT7/XT7M
1SDA101921R1
ABB
ABB Kit for DIN-rail mounting of switch according to DIN50022 for XT1 3 pole
KIT DIN50022 XT1 3p PLATE DIN
ABB
ABB ARIA Accessories. PAZBV wall mounting brackets stainless steel AISI 304, set of 4 pieces 4TBA831000C0100
ABB
CMS-201S8 Sensor 25mm 80A S800
