ABB the S2C-OVP1 overvoltage release has the function of monitoring voltage between the neutral and phase 2CSS200910R0005
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CSS200910R0005 — The S2C-OVP1 overvoltage release has the function of monitoring voltage between the neutral and phase.
Technical Specifications
- Manufacturer part number (MPN)
- 2CSS200910R0005
- EAN / GTIN
- 8012542748137
- Sales unit
- pcs
- Country of Origin
- India
- Product Sales Status
- Active
- Suitable For
- S200; S300P; SN201; F200; DS201; DS202C; DS203NC; DSE201 M; SD200; DS-ARC1; S-ARC1; S200C Enhancement
- Suitable for Product Class
- Miniature Circuit Breakers MCBs; Residual Current Devices RCDs; Residual Current Breakers with Overload Protection RCBo
- Rated Voltage (U r )
- 230 V
- Number of Contacts CO
- 0
- Number of Contacts NC
- 0
- Number of Contacts NO
- 0
- Environmental Information
- document not needed
- Product Net Width
- 18 mm
- Product Net Height
- 85 mm
- Product Net Depth / Length
- 68 mm
- Declaration of Conformity - CE
- 9AKK106713A5575
- Instructions and Manuals
- 9AKK107680A3322
- ETIM 9
- EC001286 - Auxiliary device for distribution board devices
- eClass
- V11.0 : 27143502
- Object Classification Code
- Q
- Installed at the factory
- No
- Device fitting
- Miniature circuit breaker (MCB)
- Voltage type for actuating
- AC
- With auto test for earth leakage function
- No
- Suitable for max. current main contact unit
- 100 A
Standards & Compliance
- HS Code
- 8538.10
Cross References
- EAN 8012542748137
- SAP 1200640364
- Code 83057568
Product Documentation
