ABB S203-OV40 Miniature Circuit Breaker — 3P, OV curve, 40 A, 10 kA 2CDS253202R0559
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB S203-OV40 miniature circuit breaker (MCB) from the System pro M compact range. 3P, rated current In = 40 A, OV characteristic (thermomagnetic; high magnetic trip band 10–20 × In). Rated breaking capacity Icn = 10 kA (IEC 60898-1); rated operational voltage Ue 230/400 V AC. DIN-rail modular device for overload and short-circuit protection of cables and equipment. Conforms to IEC 60898-1 and IEC 60947-2. ABB order code 2CDS253202R0559, EAN 5411815227707, ABB/SAP material 1200641695, catalogue code 83053872.
Technical Specifications
- Manufacturer
- ABB
- Product family
- System pro M compact
- Type designation
- S203-OV40
- Manufacturer part number (MPN)
- 2CDS253202R0559
- EAN / GTIN
- 5411815227707
- ABB / SAP material no.
- 1200641695
- Poles
- 3P
- Tripping characteristic
- OV (magnetic band 10–20 × In)
- Rated current In
- 40 A
- Rated breaking capacity Icn
- 10 kA
- Rated operational voltage Ue
- 230/400 V AC
- Standard
- IEC 60898-1, IEC 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC 60898-1
- HS Code
- 8536.20
Cross References
- EAN 5411815227707
- SAP 1200641695
- Code 83053872
Product Documentation
