IR Markiseswitch Insert 6411
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CKA006410A0377 — Suitable for blind, roller blind and awning drives with mechanical or electronic limit switch shut-off. With two 230 V multi-way input terminals (Up/Down) for group control. With operating mode switch for the following modes: normal, louvre, base station, position. With party function (disables the local control unit) in combination with Busch-Blind control II control cover 6430-xx-xxx, 6066-xx-xxx. Wind alarm, cleaning functions can be accommodated via extension input. For control cover 6430-xx-xxx. For IR control element 6066-xx-xxx. For comfort timer control element 6455-101-500. Running time: 3 min.
Technical Specifications
- Manufacturer part number (MPN)
- 2CKA006410A0377
- EAN / GTIN
- 4011395076484
- HS code
- 8536.90
- Sales unit
- pcs
- Instructions and Manuals
- 2CKA000073B6599
- Wiring Diagram
- 2CKA000097E0076
- Mounting Type
- Flush Mounted
- Type of Fastening
- Mounting with Screw
- Modular Components Included
- Flush Mounted Insert with Mounting Plate
- Ambient Air Temperature
- Operation 0 ... +35 °C
- Degree of Protection
- IP20
- Number of Outputs
- 2
- Rated Voltage (U r )
- 230 V
- Auxiliary Voltage AC/DC
- 230 V AC/DC
- Rated Current (I n )
- 3 A
- Rated Frequency (f)
- 50 Hz
- Maximum Switching Power
- 690 W
- Load Type
- Electrical Drives
- Design Range
- Platform 63; Busch-Duro 2000 SI; Reflex SI; Busch-balance SI; future linear; Busch-axcent; solo; Pure Stainless Steel; carat; Busch-Dynasty; impuls; alpha
- Design Range Variant
- Busch-Duro 2000 SI; Busch-Duro 2000 SI Linear; Reflex SI; Reflex SI Linear; future; future linear; Busch-axcent; Busch-axcent pur; alpha exclusive; alpha nea
- Surface Finishing
- Untreated; Glossy
- Material
- Thermoplastic
- RAL Number
- Similar to RAL 9005
- Color
- black
- Product Net Width
- 0.06 m
- Product Net Height
- 0.06 m
- Product Net Depth / Length
- 0.072 m
- Built-In Depth ( t 2 )
- 32 mm
- Dimension Diagram
- 2CKA000097E0661
- Declaration of Conformity - CE
- 2CKA100000E1576
- EU Data Act Applicability and Compliance
- Not Applicable
- ETIM 9
- EC000615 - Venetian blind control unit
- eClass
- V11.0 : 27144027
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4011395076484
- SAP 1000219760
- Code 8924869
