ABB 2CCA703901R0001 multi indicator light with 3 green LEDs Voltage range = 415-230 VACPDC Module width 0,5
Pricing
Request a quote
We reply within 24 hours
Overview
ABB 2CCA703901R0001 multi indicator light with 3 green LEDs Voltage range = 415-230 VACPDC Module width 0,5 is listed under Control & Automation / Pushbuttons & Pilot Lights. Sales unit: pcs; Package quantity: 10 pcs; Tightening Torque: 1.2-1.5 N·m; Lamp Type: LED; Switch Type: Double Interrupting Contacts; Material of Conductor: Copper.
Technical Specifications
- Manufacturer part number (MPN)
- 2CCA703901R0001
- EAN / GTIN
- 7612271413316
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Number of LEDs
- 3
- Tightening Torque
- 1.2-1.5 N·m
- Lamp Type
- LED
- Switch Type
- Double Interrupting Contacts
- Material of Conductor
- Copper
- Remarks
- Sealable in the On and Off positions
- Cover Color
- Green
- Lamp Color
- Green
- Connecting Capacity
- Solid 1x1…6 mm²; Solid 2x2.5 mm²; Flexible 1x0.75…2x2.5 mm²
- Service Life
- LED Indicator 50000 hour
- Short-Circuit Current Rating (SCCR)
- 3 kA
- Rated Voltage (U r )
- 415 V
- Rated Operational Voltage
- 415 / 230 V AC
- Rated Insulation Voltage (U i )
- 250 V
- Voltage Range
- 230 ... 415 V AC
- Rated Impulse Withstand Voltage (U imp )
- 4 kV
- Auxiliary Voltage AC/DC
- LED Indicator 230…415 V AC
- Input Voltage Type
- AC
- Rated Current (I n )
- 16 A
- Rated Frequency (f)
- 50/60 Hz
- Power Loss
- Total 0.47-1 W
- Power Watt
- 1.2 W
- Color
- Green, green, green
- Ambient Air Temperature
- Operation -25...+55 °C; Storage -40...+70 °C
- Environmental Information
- 2CCC441002C0201
- Width in Number of Modular Spacings
- 0.5
- Product Net Width
- 9 mm
- Product Net Height
- 85 mm
- Product Net Depth / Length
- 68 mm
- Built-In Depth ( t 2 )
- 68 mm
- EPLAN Data
- 9AAC407653_EPLAN
- CB Certificate
- 9AKK108466A3847
- Declaration of Conformity - CE
- 2CCC441015D0201
- Declaration of Conformity - UKCA
- 9AKK108467A6138
- VDE Certificate
- 9AKK108466A3837
- ETIM 9
- EC001657 - Indicator light for distribution board
- UNSPSC
- 39121534
- eClass
- V11.0 : 27142324
- Object Classification Code
- P
- Standards
- EN60068-2-1; EN60068-2-2; EN60068-2-30; DIN EN 62094-1; UL508
- Colour calotte
- Green
- Max. lamp power
- 1.2 W
- Voltage type
- AC
- Country of origin
- Switzerland
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 7612271413316
- SAP 1000406563
- Code 8482440
Product Documentation
More from ABB
ABB
Lysbueautomat S-ARC1 M B10
2CSA275901R9105
ABB
ABB JMKL16.4HF Conduit Bend, Halogen-Free, Ø16 mm, 90°, Impact Class 2 J
ABB
ABB 1SDA066969R1 KIT Flexible BARS 3PCS XT4
ABB
ABB 1SDA066646R1 Plate FOR Mechanical Interlock FOR PLUG-IN-Withdrawable Circuit-Breaker XT4
ABB
ABB VFI online double conversion,400V,9000W,RS232,USB,COM slot,INCLUDES28X8AH batteries mounted linked and tested 4NWP103584A1010
ABB
ABB VFI online double conversion,400V,13500W,RS232,USB,COM slot,includes 2X36X8AH batteries mounted linked and tested 4NWP103584B1520
ABB
EKIP COM RS-485 XT2/4 INT F/P
1SDA105175R1
ABB
Impressivo SENT.PL. DAB Radio Aluminium
2CKA008200A0253
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
