ACT20P current signal conditioner, 4-20 mA input to 4-20 mA output with 3-way galvanic isolation.
ACT20P current signal conditioner, 4-20 mA input to 4-20 mA output with 3-way galvanic isolation.
| Series | ACT20P |
| Input | 0/4–20 mA |
| Output | 0/4–20 mA |
| Isolation | 3-way, 2.5 kV |
| Accuracy | ±0.1% |
| Response time | <100 ms |
| Power supply | 24 VDC |
| Width | 6 mm |
| Mounting | DIN rail |
| Operating temp | -25 to +70°C |
