Schneider TeSys LRD14 Thermal Overload Relay 7-10A

Name: Schneider TeSys LRD14 Thermal Overload Relay 7-10A
Brand: Schneider Electric
SKU: CB-SCH-032

Schneider Electric · Switchgear & Protection · Overload Relays · France · se.com

Part Number
LRD14 · HS 8536.20

Schneider TeSys LRD14 Thermal Overload Relay 7-10A

TeSys LRD14 three-pole thermal overload relay, 7-10A range. Class 10A trip, 1NO+1NC signalling, manual/auto reset selectable.

Technical Specifications

Series

TeSys LRD, Current Range: 7-10A, Trip Class: 10A, Poles: 3, Auxiliary Contacts: 1NO + 1NC, Reset: Manual / Auto selectable, Terminal Type: Screw clamp, Mounting: Directly under LC1D09-D38

Properties

Primary standard

IEC 60947-4-1; UL 508

Compatibility

Direct mount under LC1D09 to LC1D38 contactors. LAD7B106 base for stand-alone use.

Standards

IEC 60947-4-1
