TeSys LRD10 three-pole thermal overload relay, 4-6A adjustment range. Class 10A trip, 1NO+1NC signalling, manual/auto reset.
TeSys LRD10 three-pole thermal overload relay, 4-6A adjustment range. Class 10A trip, 1NO+1NC signalling, manual/auto reset.
| Series | TeSys LRD, Current Range: 4-6A, Trip Class: 10A, Poles: 3, Auxiliary Contacts: 1NO + 1NC, Reset: Manual / Auto selectable, Terminal Type: Screw clamp, Mounting: Directly under LC1D09-D38 or stand-alone with LAD7B106 |
| Primary standard | IEC 60947-4-1; UL 508 |
Direct mount under LC1D09 to LC1D38 TeSys D contactors. Stand-alone with LAD7B106 base.
