TeSys LRD07 three-pole thermal overload relay, adjustment range 1.6-2.5A. Class 10A trip, manual/auto reset, 1NO+1NC signalling contacts.
TeSys LRD07 three-pole thermal overload relay, adjustment range 1.6-2.5A. Class 10A trip, manual/auto reset, 1NO+1NC signalling contacts.
| Series | TeSys LRD, Current Range: 1.6-2.5A, Trip Class: 10A, Poles: 3, Auxiliary Contacts: 1NO + 1NC, Reset: Manual / Auto selectable, Terminal Type: Screw clamp, Mounting: Directly under LC1D09-D38 or stand-alone with LAD7B106 |
| Primary standard | IEC 60947-4-1; UL 508 |
Mounts directly under LC1D09 to LC1D38 contactors. Use LAD7B106 base for stand-alone mounting.
