Fluke 700G27 digital test gauge 0-700 bar (10000 PSI). Hydraulic system commissioning, pressure relief valve setting, high-pressure calibration.
Fluke 700G27 digital test gauge 0-700 bar (10000 PSI). Hydraulic system commissioning, pressure relief valve setting, high-pressure calibration.
| Part | 700G27 |
| Range | 0 to 10000 PSI / 0 to 700 bar |
| Accuracy | ±0.05% FS |
| Media compatibility | gas + liquid (316L SS) |
| Pressure connection | 1/4 NPT male (standard) — 1/8 NPT/BSP adapters available |
| Battery | 9V alkaline or 4× AA |
| Display | 5-digit LCD with backlight |
| Data logging | 8000 readings (700G series via 700G/TRACK kit) |
| Enclosure | IP67 |
| Material | 316L SS |
| Pressure rating | 0 to 10000 PSI / 0 to 700 bar |
| Temperature range | -20 to +60°C |
| IP rating | IP67 |
| MOQ | 1 |
Supports 25 engineering units (bar, PSI, kPa, MPa, inH2O, mmHg, inHg, kg/cm², atm, torr, etc.). Auto-switches between vacuum + positive pressure.
