Bimetal thermal overload relay, 2.4-4A, Class 10A. For DILM7-DILM15. Operating range -25 to +60 °C, IP20 enclosure. P/N ZB12-4.
Bimetal thermal overload relay, 2.4-4A, Class 10A. For DILM7-DILM15. Operating range -25 to +60 °C, IP20 enclosure. P/N ZB12-4.
| Current setting | 2.4 - 4 A |
| Class | 10A |
| Phase-loss sensitive | yes |
| Aux | 1 NO + 1 NC |
| Temperature range | -25 to +60 °C |
| IP rating | IP20 |
| Primary standard | IEC/EN 60947-4-1 |
| Dimensions | 76 x 45 x 74 mm |
| Weight | 0.18 kg |
